Salient Features
  • Intelligent Enclosure Management
  • Individual drive power management
  • Hot swap design for easy maintenance and management
  • Tool-less drive trays

Specification

Model i9062 JBOD
Drive Bays 60 x 3.5" hot-swap SATA/SAS drive bays
Power Supply Redundant 1400W Platinum Level (1+1) power supplies 80PLUS (92%-94% efficiency)
Dimension / Form Factor 4U Storage JBOD Chassis
General
  • Number of Expander: Single/Dual
  • Expander Chip: Broadcom SAS3x36R + Broadcom SAS3x48
  • Host/Expansion Interface: 6 x Mini SAS HD (SFF-8644) per expander module
Drive Interface
  • 12Gb & 6Gb SAS if using dual expanders
  • 12Gb & 6Gb SAS/SATA if using single expander
Systems Cooling Fans
  • 4 x 80x38mm hot swap fans
  • 5 Nos. x 80mm rear hot-swap exhaust PWM fan(s)
Dimensions HxWxD : 175.8 mm x 438 mm x 865.3 mm
