Invento i5046 Purley Series

2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors, Single Socket LGA-3647 (Socket P) supported, CPU TDP support Up to 205W TDP
Up to 1.5TB 3DS ECC RDIMM, DDR4-2933MHz; Up to 1.5TB 3DS ECC LRDIMM, DDR4-2933MHz, in 6 DIMM slots
1 PCI-E 3.0 x8 (in x16), 1 PCI-E 3.0 x32 Left Riser slot
Dual LAN with 10GBase-T with Intel® X722 + X557
4 x 3.5"(tool-less) or 2.5"(screw) hot-swap SAS3/SATA drive bays
3 x 40x56mm counter-rotation PWM fan(s)
500W Redundant Power Supply Platinum level (92% Efficiency)

Model	i5046
Processor Support	1 x 2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors, Single Socket LGA-3647 (Socket P) supported, CPU TDP support Up to 205W TDP
Core Logic	Intel® C622 Chipset
Memory	6 x DIMM slots; Up to 1.5TB 3DS ECC RDIMM, DDR4-2933MHz; Up to 1.5TB 3DS ECC LRDIMM, DDR4-2933MHz
Expansion Slot	PCI-E Slots 1 PCI-E 3.0 x8 (in x16 slot), 1 PCI-E 3.0 x32 Left Riser Slot 6 M.2 M.2 Interface: PCI-E 3.0 x4 and SATA Form Factor: 2280, 22110 Key: M-Key Double Height Connector
RAID Options	SATA: Intel® C622 controller for 10 SATA3 (6 Gbps) ports; RAID 0,1,5,10
Drive Bays	4 x 3.5"(tool-less) or 2.5"(screw) hot-swap SAS3/SATA drive bays Optional 1 x 2.5" internal fixed drive bay OR 10 x 2.5"(tool-less) hot-swap SAS3/SATA drive bays
Network Controller	Dual LAN with 10GBase-T with Intel® X722 + X557 1 x RJ45 Dedicated IPMI LAN port
Graphics	ASPEED AST2500 BMC
IPMI	Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support ASPEED AST2500 BMC
Cooling Feature	3 x 40x56mm counter-rotation PWM fan(s)
Onboard I/O	USB: 7 USB 2.0 ports (2 rear + 5 via headers), 5 USB 3.0 ports (2 rear + 2 via headers + 1 Type A) Video Output: 1 VGA port(s) Video Output: 1 VGA port Serial Port: 2 COM Ports (1 rear, 1 header) TPM: 1 TPM Header
Power Supply	500W Redundant Power Supply Platinum level (92% Efficiency)
Dimension / Form Factor	1U Rackmount
