Invento i532 Purley Series

i532

Invento i532 Purley Series

Salient Features
  • Up to 4 Tesla P100 SXM2 GPUs
  • Up to 80 GB/s GPU-to-GPU NVLINK
  • Optimized for GPUDirect RDMA
  • Dual socket P (LGA 3647) supports Intel® Xeon® Scalable Processors, 3 UPI up to 10.4GT/s
  • Up to 1.5TB ECC 3DS LRDIMM, up to DDR4-2666MHz; 12 DIMM slots
  • 4 PCI-E 3.0 x16 slots
  • 2 Hot-swap 2.5" SAS/SATA drive bays, 2 Internal 2.5" drive bays
  • 2x 10GBase-T LAN ports via Intel X540
  • 2000W Redundant Power Supplies Titanium Level (96%)

Specification

Model i532
Processor Support 2 X Intel® Xeon® Scalable Processors, 3 UPI up to 10.4GT/s
Core Logic Intel® C621 chipset
Memory
  • 12 x DIMM slots;
  • Up to 1.5TB ECC 3DS LRDIMM, up to DDR4-2666MHz
PCIe Expansion Slot 4 PCI-E 3.0 x16 slots
RAID Options SATA: SATA3 (6Gbps); RAID 0, 1, 5, 10
Drive Bays 2 Hot-swap 2.5" SAS/SATA drive bays, 2 Internal 2.5" drive bays
Networking
  • 2 RJ45 10GBase-T ports
  • 1 RJ45 Dedicated IPMI LAN port
IPMI
  • Support for Intelligent Platform Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Network Controllers
  • Intel® i210 Gigabit Ethernet controller
  • Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
  • 1x Realtek RTL8211E PHY (dedicated IPMI)
Power Configuration ACPI / APM Power Management
Onboard I/O
  • SATA: 4 SATA3 (6Gbps) ports
  • USB: 2 USB 3.0 ports (rear)
  • Video: 1 VGA port
  • DOM: Fast UART 16550 header
Power Supply 2000W Redundant Power Supplies Titanium Level 80PLUS (96%)
Dimension / Form Factor 1U Rackmount
