Invento i629 Purley Series

Dual Socket P (LGA 3647) support 2nd Gen Intel® Xeon® Scalable processors (Cascade Lake/Skylake)
Up to 6TB 3DS ECC DDR4-2933MHz RDIMM/LRDIMM; 24 DIMM slots
1 PCI-E 3.0 x16 slot (FH, 10.5" L), 5 PCI-E 3.0 x8 slots (FH, 10.5" L), 1 PCI-E 3.0 x8 slot (LP), 1 PCI-E 3.0 x8 slot (internal LP)
4 x 1GbE LAN ports via Intel i350AM4
Up to 12 Hot-swap 3.5" drive bays
4 Nos. Heavy duty 8cm fans
1000W High efficiency Redundant Power supply unit; Titanium Level (96% Efficiency)

Model	i629
Processor Support	2 X 2nd Gen Intel® Xeon® Scalable processors (Cascade Lake/Skylake)
Core Logic	Intel® C621 chipset
Memory	24 x DDR4 DIMM slots; Supports up to 6TB 3DS ECC DDR4-2933MHz† RDIMM/LRDIMM, Supports Intel® Optane DCPMM
PCIe Expansion Slot	1 PCI-E 3.0 x16 slot (FH, 10.5" L), 5 PCI-E 3.0 x8 slots (FH, 10.5" L), 1 PCI-E 3.0 x8 slot (LP), 1 PCI-E 3.0 x8 slot (internal LP)
RAID Options	SATA3 (6Gbps) with RAID 0, 1 SATA2 (3Gbps) with RAID 0, 1, 5, 100
Drive Bays	Hot-swap: 12 Hot-swap 3.5" drive bays 12 SATA3 ports by default; Optional 8 SAS3 + 4 NVMe/SAS3 M.2: 1 M.2 PCI-E 3.0 x4 M-Key NVMe or 1 M.2 M-Key SATA3 (2240/2260/2280/22110) via optional riser card 2 M.2 PCI-E 3.0 x4 M-Key NVMe (2260/2280/22110) via optional add-on card
Network Controllers	4 x 1GbE LAN ports via Intel i350AM4
IPMI	Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support ASPEED AST2500 BMC
Cooling Feature	4 Heavy duty 8cm fans
Onboard I/O	SATA: 12 SATA3 (6Gbps) ports SAS: 8 SAS3 + 4 SAS3/NVMe support optional LAN: 4 RJ45 Gigabit Ethernet LAN ports, 1 RJ45 Dedicated IPMI LAN port USB: 3 USB 3.0 ports (2 rear, 1 Type A) Video: 2 VGA ports (1 rear, 1 onboard) Serial Port / Header: 1 Serial header DOM: 2 DOM (Disk on Module) ports
Power Supply	1000W High efficiency Redundant Power supply unit; Titanium Level (96% Efficiency)
Dimension / Form Factor	2U Rackmountable
