Invento i645 Purley Series

i645

Invento i645 Purley Series

Salient Features
  • Web Server, Firewall Apps.
  • Corporate-Wins, DNS, Print, Login
  • Gateway, provisioning servers
  • Compact Network Appliance
  • Cloud Computing
  • Dual socket P (LGA 3647) supports Intel® Xeon® Scalable Processors, Dual UPI up to 10.4GT/s
  • Up to 1.5TB ECC 3DS LRDIMM, up to DDR4-2666MHz; 12 DIMM slots
  • 4 PCI-E 3.0 x8 (FHHL) slots, 2 PCI-E 3.0 x8 (LP) slots, 1 PCI-E 3.0 x16 for Add-on-Module, 1 PCI-E M.2 SSD slot
  • 8 Hot-swap 3.5" SAS/SATA drive bays with SGPIO, 2 Fixed 3.5" drive bays
  • 2x 1GbE LAN ports via Intel C621
  • M.2 support
  • 1200W Redundant Power Supplies Titanium Level (96% Efficiency)

Specification

Model i645
Processor Support 2 X Intel® Xeon® Scalable Proc essors, Dual UPI up to 10.4GT/s
Core Logic Intel® C621 Chipset
Memory
  • 12 x DIMM slots;
  • Up to 1.5TB ECC 3DS LRDIMM, up to DDR4-2666MHz
PCIe Expansion Slot
  • 4 PCI-E 3.0 x8 (FHHL) slots,
  • 2 PCI-E 3.0 x8 (LP) slots,
  • 1 PCI-E 3.0 x16 for Add-on-Module,
  • 1 PCI-E M.2 SSD slot
RAID Options RAID 0, 1, 5, 10 support
Drive Bays 8 Hot-swap 3.5" SAS/SATA drive bays with SGPIO, 2 Fixed 3.5" drive bays
IPMI
  • Support for Intelligent Platform Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Networking
  • 2 RJ45 Gigabit Ethernet ports
  • 1 RJ45 Dedicated IPMI LAN port
Graphics ASPEED AST2500 BMC
Power configurations ACPI / APM Power Management
Onboard I/O
  • SATA: 12 SATA3 (6 Gbps) ports
  • USB: 4 USB 3.0 ports (rear)
  • Video: 1 VGA port
  • DOM: 2 DOM (Disk on Module) ports
Power Supply 1200W Redundant Power Supplies Titanium Level (96% Efficiency) 80PLUS
Dimension / Form Factor 2U Rackmount
