Invento i8409 EPYC

i8409 EPYC

Invento i8409 EPYC

Salient Features
  • Supports Dual AMD EPYC™ 9005/9004 Series Processors
  • Supports NVIDIA HGX H200 4-GPU’s
  • Upto 24 DDR5 DIMM slots
  • Upto 6 PCI-E 5.0 slots
  • 2 x 1GbE and 2 x 10GbE LAN ports
  • Up to 8 Hot-swap 2.5" drive bays
  • 7 Hot-swap cooling fans
  • 2+1 3000W 80 PLUS Titanium Redundant power supplies

Specification

Model i8409 EPYC
Processor Support
  • Dual AMD EPYC™ 9005/9004 Series Processors
  • cTDP up to 400W
Core Logic System on Chip (SoC)
Memory
  • 24 x DIMM slots
  • DDR5 Memory supported
  • Support Upto 6000Mhz
PCIe Expansion Slots
  • 6 x LP PCIe Gen5 x16 slots,
  • 1 x OCP NIC 3.0 (Disabled)
IPMI
  • Support for Intelligent Platform Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Graphics ASPEED AST2600 BMC
Drive Bays
  • 4 x 2.5" Gen5 NVMe/SATA/SAS-4 hot-swap bays
  • 4 x 2.5" Gen5 NVMe hot-swap bays
  • 1 x M.2 slot with PCIe Gen4 x4 interface
Networking
  • 2 x 10Gb/s LAN ports via Broadcom® BCM57416
  • 2 x 1Gb/s LAN ports via Intel® I350-AM2
  • 1 RJ45 Dedicated IPMI LAN port
Cooling feature 7 x Heavy duty Hot-swap Cooling fans
GPU Supports
  • NVIDIA HGX™ H200 4-GPU
  • 4th-Generation NVIDIA® NVLink™ 900GB/s
Operating Systems Support Microsoft Windows 2019/2022/2025, RHEL 9.x, Ubuntu 20.04/22.04/24.04, SUSE, CentOS
Onboard I/O
  • USB: 2 USB 3.0 ports
  • Video: 1 mDP port
  • TPM Header
Power Supply (2+1) 3000W 80 PLUS Titanium Redundant Power supplies 96% Efficiency
Dimension / Form Factor 3U Rackmountable
