Invento i901-JBOD

i901-JBOD

Invento i901-JBOD

Salient Features
  • Cloud Backup, Data Replication, or High Density Archive Storage Applications
  • 4U Storage JBOD Chassis
  • 24 x 3.5" hot-swappable HDDs bays
  • Single Expander Backplane Boards support SAS3/2 HDDs with 12Gb/s throughput
  • 1x IPMI port for Remote System Power on/off and system monitoring
  • 5 Nos. hHot-plug redundant cooling fans
  • Ideal for Cloud backup, data Replication or High density Archive Storage Applications
  • Support NTP for time synchronization & RTC battery backup
  • 800W / 1000W (1+1) 96% efficient Titanium level power supply

Specification

Model i901-JBOD
Drive Bays 24 x 3.5" hot-swappable Hard Drive bays
Power Supply 800/1000W Redundant Titanium Single Output Power Supply 96% Efficiency
Dimension / Form Factor 4U Storage JBOD Chassis
LED's On Panel 1 Network Activity LEDs
Button's On Panel
  • Power On/Off button
  • System Reset Button
  • Unit Identification (UID) button
Backplane 24-port 4U SAS3 12Gbps single-expander backplane, support up to 24 x 3.5-inch SAS3/SATA3 HDD/SSD
Systems Cooling Fans
  • 3 x 8cm hot-swap redundant PWM cooling fan(s)
  • 2 x 8cm hot-swap exhaust fan(s) & air shroud
